4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope

4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope
4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope 4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope 4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope

Large Image :  4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope

Product Details:
Place of Origin: ningbo china
Brand Name: Linkai
Certification: iso ce
Model Number: hss
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: get the latest
Packaging Details: wooden case
Delivery Time: 5-8work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200sets/day
Detailed Product Description
Name: Manual Cable Pulling Winch Cable Meter: Standard 20m
Rated Load: 4T Net Weight: 13kg
After Service: Available Type: Cable Pulling Tools
High Light:

electrical wire pulling tools

,

stringing pulling tools

Manual Cable Pulling Winch Machine Tirfor Winch With 20M Wire Rope



Quick information:

1. Manual cable pulling winch machine

2.Standard length of cable meter is 20M

3. Type Trifor lifting hoist with stainless steel wire

4. Donghuan Brand

5. Rated load 4T

6. weight net 14kg

7. electrical cable pulling tools and accessories



HSS Wire Rope Tackle Block Configuration:

It has three functions of lifting, pulling and tensioning. It is suitable for long distance lifting or pulling in the field without power source.

Tirfor lifting hoist with stainless steel wire HSS Hand wire rope pulling winch
Item number 14183 14184 14185 14186
Model HSS408 HSS416 HSS432 ISS454
Rated Lifting/Pulling (KN) 8/12.5 16/25 32/50 54
Once journey(MM) ≥40 ≥40 ≥16 ≥20

Diametre of

steel rop (MM)

Φ8 Φ11.6 Φ16 Φ22

Standard length

of steel rope (M)

20 20 20 20
Net weight (KG) 6.8 13 25 52

Hand wrenching

at the rate load (N)

≤343 ≤400 ≤441 ≤550
Encasement dimension (MM) 420x106x250 530x126x315 660x160x360 930x390x150

4 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope 04 T Manual Cable Pulling Winch Machine / Tirfor Winch With 20M Wire Rope 1
